Time Mark 330-L-10SEC Operate Delay Timer
Regular price
$73.17
inc. VAT
Couldn't load pickup availability
Relays, Series
Item #
330-L-10SEC
Operate Delay Timer
Series Information
Specifications
| Ships Factory Direct | No |
|---|---|
| Manufacturer Part Number | 98084601 |
| Item Number | 330-L-10SEC |
| Manufacturer | Time Mark |
| Family Series | Time Mark Relays |
| Mode of Operation | Delay Timer |
| Multi-Function | No |
| Contacts | DPDT |
| Mounting Type | Socket |
| Status Indicator | LED |
| Time Range Adjustment | Onboard |
| Adjustment Operator | Knob |
| Timing Range | 1 |
| Max Time | 10 s |
| Time Range (Seconds) | 0-1, 0-2, 0-3, 0-4, 0-5, 0-10 |
| Coil Voltage | 10-28 VAC, 10-28 VDC |
| Nominal Coil Voltage | 12 VAC, 12 VDC, 24 VAC, 24 VDC |
| Voltage (AC) | 10-28 VAC |
| Voltage (DC) | 10-28 VDC |
| Contact Rating (A) | 10 A |
| Termination | 8 Pin |
| Approvals | CSA, UL |
| Net Weight | 0.3125 lbs |
| Gross Weight | 0 lbs |
