Time Mark 360-H-1MIN Time Delay Relay

In stock
SKU: 360-H-1MIN
$72.43 inc. VAT
  • Solid-State Design
  • 10 Amp Relay Contacts
  • UL Recognized and CSA Certified.
  • Voltage L = 10-28V AC/DC
  • Voltage H = 40-260V AC/DC

  • DESCRIPTION
  • The Models 330 and 360 Operate Delay Timers are
    designed for a wide range of industrial applications.
    Examples include automatic and machine tool control
    circuits, HVAC circuits, and warm-up delay circuits. The
    Model 330 is a DPDT potentiometer (knob-adjust) timer.
    The Model 360 is a DPDT, high-accuracy digital input
    timer. Solid-state timing circuits in each model drive an
    internal electromechanical relay.
    Each model is functionally interchangeable. They are
    available in a variety of voltage and timing ranges to cover
    all possible applications.
    An “SG” version of this model is available using silver with
    gold flash contacts.
    Models 330     and 360 are UL Recognized and CSA
    Certified.
    ⚫ Solid-State Design
    ⚫ 10 Amp Relay Contacts
    ⚫     Multiple Voltage and Timing Ranges
    ⚫ 5-Year Unconditional Warranty
    MODEL 330
    MODEL 360
    Operate Delay Timers
  • SPECIFICATIONS
    MODEL     330 (knob adj.) 360 (digital)
    Voltage     L = 10-28V AC/DC
    H = 40-260V AC/DC
    Timing range     10SEC: 1 - 10 Sec.
    60SEC: 1 - 60 Sec.
    180SEC: 1 - 180 Sec.
    300SEC: 1 - 300 Sec.
    0.1SEC: 0.1 - 102.3 Sec.
    1SEC: 1 - 1023 Sec.
    1MIN: 1 - 1023 Min.
    1HR: 1 - 1023 Hr.
    Accuracy     ± 5% ± 2%
    Repeatability     ± 2% ± 0.1%
    Recycle time     100ms
    Operating temp     -20°F to 140°F
    Contacts     DPDT
    Contact rating     10A at 240VAC resistive
    Transient protection     775V, 80 Joules
    Humidity tolerance     0 - 97% w/o condensation
    Enclosure material     NORYL Plastic
    Mounting     8-pin socket (*not included) **
    Weight     5 oz.
    Agency approval     UL Recognized and CSA Certified
    Additional Options     /C = Custom (Voltage and/or Timing)
    /SG = Silver with Gold Flash Contacts
